Table 3-5 Plastics Kit component descriptions and part numbers
Item Component Spare part number
Plastics Kit, includes: M07215-001
(1) I/O frame
(2) Fingerprint reader insert
(3) SIM card insert
(4) Smart card reader insert
Miscellaneous parts
To identify the miscellaneous parts, use this table.
Table
3-6 Miscellaneous part descriptions and part numbers
Component Spare part number
AC adapters
65 W, nPFC, USB-C, RC, 1.8 m (5.9 ft) L32392-001
65 W, nPFC, USB-C, travel adapter L21487-001
45 W, nPFC, SMART, RC, 4.5 mm, nonslim 741727-001
45 W, nPFC, USB-C, RC, 1.8 m (5.9 ft) L43407-001
45 W, nPFC, wall mount, USB-C, 1.8 m (5.9 ft)
Screw Kit M07205-001
Power adapter, duckhead, C5NS
South Korea L50818-001
North America L50818-002
Power adapter, duckhead
Japan L33157-001
24 Chapter 3 Illustrated parts catalog
