HP EliteBook 840 G8 User Manual

NFC module
To remove the NFC module, use this procedure and illustration.
Table 6-9 NFC module description and part number
Description Spare part number
NFC module M07214-001
NFC module cable (included in Cable Kit) M07101-001
Before removing the NFC module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 33).
2. Remove the bottom cover (Bottom cover on page 33).
3. Remove the battery (see Battery on page 43).
Remove the NFC module:
1. Disconnect the system board cable from the ZIF connector on the NFC module (1).
2. Disconnect the touchpad cable from the reverse ZIF connector on the NFC module (2).
3. Use a tool to release the module (3), and then remove the module from the computer (4). The module is
secured with adhesive.
Reverse this procedure to install the NFC module.
Fan
To remove the fan, use this procedure and illustration.
Component replacement procedures 53

HP EliteBook 840 G8 Specifications

General

RAM	Up to 64 GB DDR4-3200 SDRAM
Storage	Up to 2 TB PCIe NVMe SSD
Graphics	Intel Iris Xe Graphics
Battery	HP Long Life 3-cell, 53 Wh Li-ion
Wireless	Intel Wi-Fi 6 AX201 (2x2) and Bluetooth 5 combo
Bluetooth	Bluetooth 5
Processor	11th Generation Intel Core i5/i7
Display	14" diagonal, FHD (1920 x 1080)
Operating System	Windows 10 Pro
Ports	2x Thunderbolt 4, 2x USB 3.1 Gen1, 1x HDMI 2.0, 1x headphone/microphone combo, 1x AC power
Webcam	720p HD camera
Audio	Dual stereo speakers, dual array microphones
Security	HP Sure Start, HP Sure Sense, HP Sure Click
