Before removing the memory, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 33).
2. Remove the bottom cover (Bottom cover on page 33).
3. Disconnect the battery cable from the system board (see Battery on page 43).
If you are replacing a memory module, remove the existing memory module:
1. Use the tab (1) to lift the cover o the memory modules (2). The cover is held in place by clips on the
system board.
Component replacement procedures 35
