Display assembly subcomponents
Item Component Spare part number
(1) Bezel 821160-001
(2) Left hinge cover (a) and right hinge cover (b) (spared with hinges) 821166-001
(3) Left hinge (a) and right hinge (b) 821166-001
(4) Microphone module L17980-001
(5) Camera module (includes microphone) L17986-001
(6) Display/camera cable L17982-001
(7) WLAN antenna (spared with back cover)
(8) WWAN antenna (spared with back cover)
(9) Raw panel
HD L17988-001
FHD L17987-001
(10) Back cover (includes antennas) 821161-001
Display assembly subcomponents 21
