3. Tilt the battery down (2), slide the battery (3) into the bay until the battery release latch snaps,
and then slide the battery release latch to the left to lock the battery.
NOTE: In the locked position there will be no red color shown in the battery release latch slot.
Removing a battery
To remove the battery:
CAUTION: Removing a battery that is the sole power source for the computer can cause loss of
information. To prevent loss of information, save your work and shut down the computer through
Windows before removing the battery.
1. Turn the computer upside down on a flat surface, with the battery bay away from you.
2. Slide the battery release latch (1) to release the battery.
3. Slide the battery outward (2), and then lift the outer edge of the battery (3) to remove it from the
computer.
Setting power options 41
