HP Elitebook 9480m User Manual

●
To specify a boot device from the Express Boot menu, select your preference within the allotted
time, and then press enter.
●
To prevent the computer from defaulting to the current MultiBoot setting, press any key before
the allotted time expires. The computer will not start until you select a boot device and press
enter.
●
To allow the computer to start according to the current MultiBoot settings, wait for the allotted
time to expire.
Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unified Extensible Firmware Interface (UEFI) that allows you to run
diagnostic tests to determine whether the computer hardware is functioning properly. The tool runs
outside the operating system so that it can isolate hardware failures from issues that are caused by
the operating system or other software components.
To start HP PC Hardware Diagnostics UEFI:
1. Turn on or restart the computer, quickly press esc, and then press f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device on page 80.
b. Hard drive
c. BIOS
2. When the diagnostic tool opens, use the keyboard arrow keys to select the type of diagnostic
test you want to run, and then follow the on-screen instructions.
NOTE: If you need to stop a diagnostic test, press esc.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
NOTE: Instructions for downloading HP PC Hardware Diagnostics (UEFI) are provided in English
only.
There are two options to download HP PC Hardware Diagnostics to a USB device:
Option 1: HP PC Diagnostics homepage—Provides access to the latest UEFI version
1. Go to
http://hp.com/go/techcenter/pcdiags.
2. Click the UEFI Download link, and then select Run.
Option 2: Support and Drivers pages—Provides downloads for a specific product for earlier and later
versions
1. Go to
http://www.hp.com.
2. Point to Support, located at the top of the page, and then click Download Drivers.
3. In the text box, enter the product name, and then click Go.
– or –
Click Find Now to let HP automatically detect your product.
80 Chapter 12 Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI)

HP Elitebook 9480m Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Intel segment tagging	Enterprise
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 8 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Number of HDDs installed	1
Display surface	Matt
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Number of built-in speakers	2
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Number of SATA III connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Sustainability certificates	ENERGY STAR
Operating shock	40 G
Operating altitude	-15.24 - 3048 m
Non-operating shock	200 G
Operating vibration	0.75 G
Non-operating altitude	-15.24 - 12192 m
Non-operating vibration	1.5 G
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Battery capacity	52 Wh
AC adapter power	45 W
AC adapter output voltage	19.5 V
Pointing device	Touchpad
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	3 MB
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4300 Mobile series
Processor socket	BGA 1168
Processor codename	Haswell
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Operating system installed	Windows 7 Professional
Processor code	SR1EE
Processor ARK ID	80343
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	18.9 mm
Weight	1610 g
