c. Gently press the memory module (3) down, applying pressure to both the left and right
edges of the memory module, until the retention clips snap into place.
CAUTION: To prevent damage to the memory module, be sure that you do not bend the
memory module.
8. To replace the memory module compartment door:
a. Turn the computer upside down on a flat surface, with the memory module compartment
toward you.
b. Align the door tabs with the edge of the computer and slide the door toward the back of the
computer at a slightly tilted angle (1).
68 Chapter 10 Maintenance
