b. To insert the new battery, slide one edge of the replacement battery under the holder’s lip with the
positive side up (1). Push the other edge down until the clamp snaps over the other edge of the
battery (2).
Type 3
a. Pull back the clip (1) that is holding the battery in place, and remove the battery (2).
b. Insert the new battery and position the clip back into place.
NOTE: After the battery has been replaced, use the following steps to complete this procedure.
8. Replace the computer access panel.
9. Reconnect the power cord and any external devices, and then turn on the computer.
10. Reset the date and time, your passwords, and any special system setups using Computer Setup.
11. Lock any security devices that were disengaged when the computer access panel was removed.
127
