Item Description
(8) Bezel blank, slim optical drive
(9) Rear fan
(10) Option boards:
USB-C option board
HDMI option board
DisplayPort option board
VGA option board
Thunderbolt 3 option board
Fan sink (includes replacement thermal material)
(11) For use in models with a 65 W processor
(12) For use in models with up to a 95 W processor
(13) Solid-state drives, NVMe, M.2 2280, PCIe
1 TB, TLC
512-GB
256-GB, TLC
256-GB
Optane memory module, 16-GB, TLC
(14) Front bezel
(15) Optional rear ports (HDMI, VGA, DP or USB-C port)
(16) Hood lock (solenoid)
(17) Processor (include replacement thermal material; not illustrated))
Intel Core i7-8700 processor
Intel Core i7-8700K processor
Intel Core i5-8600 processor
Intel Core i5-8600K processor
Intel Core i5-8500 processor
Intel Core i3-8033 processor
Intel Core i3-8011 processor
Intel Pentium G5600 processor
Intel Pentium G5500 processor
Intel Pentium G5400 processor
Intel Celeron G4900 processor
(18) Memory module (UDIMM, non-ECC, 1.2v, PC4-2666)
16-GB
6 Chapter 2 Illustrated parts catalog
