Hood sensor
The hood sensor is secured in a slot in the rear of the chassis.
1. Prepare the computer for disassembly (Preparation for disassembly on page 17).
2. Remove the access panel (Access panel on page 18).
3. Disconnect the cable (1) from the system board connector labeled HSENSE.
4. Using a screwdriver or similar tool, slide the sensor out of the slot in the rear of the chassis (2).
To install the hood sensor, reverse the removal procedure.
56 Chapter 4 Removal and replacement procedures
