2 Illustrated parts catalog
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Computer major components
Item Description
(1) Access panel
(2) Power supply
500 W
250 W
(3) Speaker
(4) Hood sensor
(5) Bezel blank, 5.25-inch
(6) WLAN modules
Intel Dual Band Wireless-AC 9560 802.11 AC 2x2 WiFi + Bluetooth 5.0 Combo Adapter (vPro)
Intel Dual Band Wireless-AC 9560 802.11 AC 2x2 WiFi + Bluetooth 5.0 Combo Adapter (non-vPro)
Realtek RTL8821CE 802.11 ac 1x1 WiFi + BT 4.2 Combo Adapter (MU-MIMO supported)
Realtek RTL8822BE 802.11 ac 2x2 WiFi + BT 4.2 Combo Adapter (MU-MIMO supported)
(7) SATA data cable, 17.7 inch, 2 straight ends
SATA data cable, 6 inch, 1 straight end, 1 angled end (not illustrated)
Computer major components 5
