Side components
Component
Component
1
Power button
6
Microphone/line in jack
2
hard disk drive acti
vity LED
7
HP SD media card reader (optional)
3
USB 3.0 port, fast-charging
8
Optical disc drive eject button
4
USB 3.0 port
9
Optical disc drive activi
ty LED
5
Headset/line out jack
10
Tray-load optical dis
c drive
12
Chapter 1 Product features
19
21
