Removing and installing the rear port cover
Removing the rear port cover
1. Place the computer face down on a soft flat surface. HP recommends that you set down a blanket,
towel, or other soft cloth to protect the bezel and screen surface from scratches or other damage.
2. If the security lock screw is secured, unscrew it with a T15 tamper-resistant Torx security screwdriver.
3. Press the two tabs toward each other to disengage the port cover from the chassis (1).
4. Pull the port cover toward the bottom and off the computer (2).
Installing the rear port cover
1. Be sure that all cables are connected.
2. Hold the port cover parallel to the computer and align the two tabs on the port cover with the slots in
the top of the rear port compartment.
3. Slide the port cover in until the tabs click into place (1).
Removing and installing the rear port cover 27
