14. Align the three pins on the latch with the holes in the new ODD and press the latch firmly onto the new
drive.
NOTE: You must reuse the latch removed from the old ODD.
15. Align the new ODD with the opening in the side of the computer. Push the drive in firmly until it snaps
into place.
NOTE: The ODD can be installed in only one way.
16. To replace the access panel, align the latches with the slots in the rear port compartment. Set the
access panel down (1) and press in the tabs around all sides of the panel until it is in place.
Replacing drives 59
