8. Lift the memory module compartment cover (2) away from the computer.
9. If you are replacing a memory module, remove the existing memory module:
a. Pull the retention clips (1) away from the sides of the memory module.
The memory module tilts up.
CAUTION: To prevent damage to the memory module, hold the memory module by the
edges only. Do not touch the components on the memory module.
b. Grasp the edge of the memory module (2), and gently pull the module out of the memory
module slot.
c. To protect a memory module after removal, place it in an electrostatic-safe container.
10. Insert a new memory module:
90 Chapter 8 Adding or replacing a memory module
