Right-side components
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) Optical drive Reads optical discs and, on select models, also writes to optical
discs.
(2) Optical drive light on release button Blinking: The optical drive is being accessed.
(3) USB port Connects an optional USB device.
(4) RJ-11 (modem) jack (select models only) Connects a modem cable (purchased separately).
(5) AC adapter light
●
Blinking white: The computer is in the Sleep state.
●
On white: The computer is connected to external power.
●
Amber: The battery is charging.
●
Off: The computer is not connected to external power.
(6) Power connector Connects an AC adapter.
(7) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a deterrent, but
it may not prevent the computer from being mishandled or stolen.
6 Chapter 1 Features
