IGMP Snooping 100
3. Assign the IGMP Filter to a port.
>> //cfg/l3/igmp/igmpflt (Select IGMP Filtering menu)
>>IGMP Filter# port 24 (Select port 24)
>>IGMP Port 24# filt ena (Enable IGMP Filtering on the port)
Current port 24 filtering: disabled
New port 24 filtering: enabled
>>IGMP Port 24# add 1 (Add IGMP Filter 1 to the port)
>>IGMP Port 24# apply (Make your changes active
Configuring a Static Mrouter (CLI example)
1. Configure a port to which the static Mrouter is connected, and enter the appropriate VLAN.
>> /cfg/l3/igmp/mrouter (Select IGMP Mrouter menu)
>> Static Multicast Router# add 20 (Add port 20 as Static
Mrouter port)
Enter VLAN number: (1-4094) 1 (Enter the VLAN number)
Enter the version number of mrouter [1|2]: 2 (Enter the IGMP
version number)
2. Apply, verify, and save the configuration.
>> Static Multicast Router# apply (Apply the configuration)
>> Static Multicast Router# cur (View the configuration)
>> Static Multicast Router# save (Save the configuration)
Configuring IGMP Snooping (BBI example)
1. Configure port and VLAN membership on the switch, as described in the “Configuring ports and VLANs (BBI
example)” section in the “VLANs” chapter.
2. Configure IGMP Snooping.
a. Click the Configure context button.
b. Open the IGMP folder, and select IGMP Snooping (click the underlined text, not the folder).
