Controls, ports, and LEDs
Front panel view
9
Partition Identifier
5
Monarch power button
1
Monarch blade indicator
2
UID LED
10
Physical Presence Button
6
HDD bay 1
7
HDD bay 2
3
Blade health LED
11
SUV connector
84
Blade power LEDNICs 1, 2, 3, 4
CAUTION: The SUV cable is not designed to be used as a permanent connection.
Use caution when walking near the server blade when the SUV cable is installed. Hitting or
bumping the cable might cause the port on the server blade to break. This can damage the system
board.
Overview 11
