SUV Cable and Ports
The SUV port on the front of the server blade is used in conjunction with an SUV cable to connect
the server to external devices such as a terminal emulator or monitor.
CAUTION: The SUV cable is not designed to be used as a permanent connection.
Use caution when walking near the server blade when the SUV cable is installed. Hitting or
bumping the cable might cause the port on the server blade to break. This can damage the system
board.
431
Server blade SerialUSB ports (2)
2
Video
Rear panel view
21
GBX signal connectorsPower connectors
16 Installing the server blade into the enclosure
