Mechanical Instruction
11
Go to cover page
HP L1940
Step 4. Disconnect the control PCB,
as Fig.11
the scaler pcb and power pcb
Fig.11
Fig.12
Step 5 Remove the MAIN SHIELD ASSY as
FIG.12
In warranty, it is not allowed to disassembly the LCD panel, even the
backlight unit defect.
Out of warranty, the replacment of backlight unit is a correct way
when the defect is cused by backlight (CCFL,Lamp).
LPL panel
