HP L1940 Service Manual

49
Go to cover page
HP L1940
2231 223878615649 CER2 0603 X7R 16V 100N PM10
2233 223878615649 CER2 0603 X7R 16V 100N PM10
2234 223878615649 CER2 0603 X7R 16V 100N PM10
2301 223878615649 CER2 0603 X7R 16V 100N PM10
2302 223878615649 CER2 0603 X7R 16V 100N PM10
2401 202001293721 ELCAP SM RV2 16V 10U PM20
2402 202002191725 ELCAP SM RVS 16V 10U PM20
2403 223878615649 CER2 0603 X7R 16V 100N PM10
2404 223878615649 CER2 0603 X7R 16V 100N PM10
2405 223878615649 CER2 0603 X7R 16V 100N PM10
2406 223878615649 CER2 0603 X7R 16V 100N PM10
2407 223878615649 CER2 0603 X7R 16V 100N PM10
2408 202001293721 ELCAP SM RV2 16V 10U PM20
2409 223878615649 CER2 0603 X7R 16V 100N PM10
2410 223878615649 CER2 0603 X7R 16V 100N PM10
2411 223878615649 CER2 0603 X7R 16V 100N PM10
2412 223878615649 CER2 0603 X7R 16V 100N PM10
2413 223878615649 CER2 0603 X7R 16V 100N PM10
2414 223878615649 CER2 0603 X7R 16V 100N PM10
2415 223878615649 CER2 0603 X7R 16V 100N PM10
2416 223878615649 CER2 0603 X7R 16V 100N PM10
2417 202001293721 ELCAP SM RV2 16V 10U PM20
2418 223878615649 CER2 0603 X7R 16V 100N PM10
2419 202002191725 ELCAP SM RVS 16V 10U PM20
2420 223878615649 CER2 0603 X7R 16V 100N PM10
2421 223878615649 CER2 0603 X7R 16V 100N PM10
2422 223878615649 CER2 0603 X7R 16V 100N PM10
2423 223878615649 CER2 0603 X7R 16V 100N PM10
2424 223878615649 CER2 0603 X7R 16V 100N PM10
2425 202002191725 ELCAP SM RVS 16V 10U PM20
2426 202002191725 ELCAP SM RVS 16V 10U PM20
2427 202001293721 ELCAP SM RV2 16V 10U PM20
2428 223878615649 CER2 0603 X7R 16V 100N PM10
2430 202001293721 ELCAP SM RV2 16V 10U PM20
2431 223878615649 CER2 0603 X7R 16V 100N PM10
2432 223878615649 CER2 0603 X7R 16V 100N PM10
2433 223878615649 CER2 0603 X7R 16V 100N PM10
2434 223878615649 CER2 0603 X7R 16V 100N PM10
2435 202001293721 ELCAP SM RV2 16V 10U PM20
2436 223878615649 CER2 0603 X7R 16V 100N PM10
2437 202001293721 ELCAP SM RV2 16V 10U PM20
2438 223878615649 CER2 0603 X7R 16V 100N PM10
2439 202002191725 ELCAP SM RVS 16V 10U PM20
2440 223878615649 CER2 0603 X7R 16V 100N PM10
2441 223878615649 CER2 0603 X7R 16V 100N PM10
2442 223878615649 CER2 0603 X7R 16V 100N PM10
2443 223878615649 CER2 0603 X7R 16V 100N PM10
2444 223878615649 CER2 0603 X7R 16V 100N PM10
2445 223878615649 CER2 0603 X7R 16V 100N PM10
2446 223878615649 CER2 0603 X7R 16V 100N PM10
2450 223886715478 CER1 0603 NP0 50V 4P7 PM0P25
2451 223886715478 CER1 0603 NP0 50V 4P7 PM0P25
2452 223858615636 CER2 0603 X7R 50V 10N PM10
2453 223858615636 CER2 0603 X7R 50V 10N PM10
2454 223858615636 CER2 0603 X7R 50V 10N PM10
2455 223858615636 CER2 0603 X7R 50V 10N PM10
2460 202203100179 ELCAP SM HV 25V 10U PM20
2461 223878615649 CER2 0603 X7R 16V 100N PM10
2501 223891015649 CER2 0805 X7R 25V 100N PM10
2502 223891015649 CER2 0805 X7R 25V 100N PM10
2503 202203100206 ELCAP SM HV 25V 47U PM20
2504 223878615649 CER2 0603 X7R 16V 100N PM10
2505 223878615649 CER2 0603 X7R 16V 100N PM10
2506 202203100206 ELCAP SM HV 25V 47U PM20
2508 223878615649 CER2 0603 X7R 16V 100N PM10
2510 223878615649 CER2 0603 X7R 16V 100N PM10
2511 223878615649 CER2 0603 X7R 16V 100N PM10
2513 223878615649 CER2 0603 X7R 16V 100N PM10
2514 223878615647 CER2 0603 X7R 16V 68N PM10
2515 203803513312 ELCAP RGA 25V S 47U PM20
2516 202203100179 ELCAP SM HV 25V 10U PM20
2517 223858015641 CER2 0805 X7R 50V 22N PM10
2518 223886715221 CER1 0603 NP0 50V 220P PM5
2519 202203100068 ELCAP GL 25V S 470U PM20
2521 223878615649 CER2 0603 X7R 16V 100N PM10
2523 223878615649 CER2 0603 X7R 16V 100N PM10
2525 223878615649 CER2 0603 X7R 16V 100N PM10
2529 223878615649 CER2 0603 X7R 16V 100N PM10
2531 223878615649 CER2 0603 X7R 16V 100N PM10
2601 223824619863 CER2 0603 Y5V 10V 1U P8020
2602 223824619863 CER2 0603 Y5V 10V 1U P8020
2603 223878615649 CER2 0603 X7R 16V 100N PM10
2604 223878615649 CER2 0603 X7R 16V 100N PM10
2605 223878615649 CER2 0603 X7R 16V 100N PM10
2606 223878615649 CER2 0603 X7R 16V 100N PM10
2607 223878615649 CER2 0603 X7R 16V 100N PM10
2608 223878615649 CER2 0603 X7R 16V 100N PM10
2609 223878615649 CER2 0603 X7R 16V 100N PM10
2610 223878615649 CER2 0603 X7R 16V 100N PM10
2611 223878615649 CER2 0603 X7R 16V 100N PM10
2612 223878615649 CER2 0603 X7R 16V 100N PM10
2615 223878615649 CER2 0603 X7R 16V 100N PM10
2616 202001293721 ELCAP SM RV2 16V 10U PM20
2618 223878615649 CER2 0603 X7R 16V 100N PM10
2619 223878615649 CER2 0603 X7R 16V 100N PM10
2620 223886715189 CER1 0603 NP0 50V 18P PM5
2621 223886715189 CER1 0603 NP0 50V 18P PM5
2622 202203100227 ELCAP KM 25V S 100U PM20
2623 223878615649 CER2 0603 X7R 16V 100N PM10
2624 202203100227 ELCAP KM 25V S 100U PM20
2625 223878615649 CER2 0603 X7R 16V 100N PM10
2627 222224119876 CER2 1206 Y5V 10V 10U P8020
2630 223878615649 CER2 0603 X7R 16V 100N PM10
3202 212211805669 RST SM 0603 RC0603 10K PM5
3203 212211805669 RST SM 0603 RC0603 10K PM5
3204 212211805669 RST SM 0603 RC0603 10K PM5
3206 232270260101 RST SM 0603 RC21 100R PM5
3207 232270260101 RST SM 0603 RC21 100R PM5
3209 232270260104 RST SM 0603 RC21 100K PM5
3210 232270260101 RST SM 0603 RC21 100R PM5
3211 232270260101 RST SM 0603 RC21 100R PM5
3212 232270260101 RST SM 0603 RC21 100R PM5
3216 232270260101 RST SM 0603 RC21 100R PM5
3217 232270260101 RST SM 0603 RC21 100R PM5
3218 232270260101 RST SM 0603 RC21 100R PM5
3219 232270260101 RST SM 0603 RC21 100R PM5
3221 212211805669 RST SM 0603 RC0603 10K PM5
3222 212211805669 RST SM 0603 RC0603 10K PM5
3223 232270260101 RST SM 0603 RC21 100R PM5
3224 232270260101 RST SM 0603 RC21 100R PM5
3225 232270260101 RST SM 0603 RC21 100R PM5
3226 232270260101 RST SM 0603 RC21 100R PM5
3227 232270260222 RST SM 0603 RC21 2K2 PM5
3228 232270260222 RST SM 0603 RC21 2K2 PM5
3229 232270260104 RST SM 0603 RC21 100K PM5
3230 212211805669 RST SM 0603 RC0603 10K PM5
3232 232270296001 RST SM 0603 JUMP. MAX 0R05
3233 232270467509 RST SM 0603 RC22H 75R PM1
3234 232270296001 RST SM 0603 JUMP. MAX 0R05
3235 232270467509 RST SM 0603 RC22H 75R PM1
3236 232270296001 RST SM 0603 JUMP. MAX 0R05
3237 232270467509 RST SM 0603 RC22H 75R PM1
3241 212211805635 RST SM 0603 RC0603 10R PM5
3242 212211805669 RST SM 0603 RC0603 10K PM5
3243 212211805635 RST SM 0603 RC0603 10R PM5
3244 232270260479 RST SM 0603 RC21 47R PM5
3245 232270260479 RST SM 0603 RC21 47R PM5
3246 212211805669 RST SM 0603 RC0603 10K PM5
3247 212211805669 RST SM 0603 RC0603 10K PM5
3301 212211805669 RST SM 0603 RC0603 10K PM5
3302 212211805669 RST SM 0603 RC0603 10K PM5
3306 212211805669 RST SM 0603 RC0603 10K PM5
3307 212211805669 RST SM 0603 RC0603 10K PM5
3308 232270260101 RST SM 0603 RC21 100R PM5
3309 232270260101 RST SM 0603 RC21 100R PM5
3310 212211805669 RST SM 0603 RC0603 10K PM5
3333 212211805669 RST SM 0603 RC0603 10K PM5
3338 212211805669 RST SM 0603 RC0603 10K PM5
3339 212211805669 RST SM 0603 RC0603 10K PM5
3340 232270260101 RST SM 0603 RC21 100R PM5
3401 232270260101 RST SM 0603 RC21 100R PM5
3402 232270260101 RST SM 0603 RC21 100R PM5
3404 232270281121 RST SM 0603 RC21 120R PM5
3405 232270281121 RST SM 0603 RC21 120R PM5
3406 232270281121 RST SM 0603 RC21 120R PM5
3408 232270462491 RST SM 0603 RC22H 249R PM1
3409 232270260479 RST SM 0603 RC21 47R PM5
3413 232270260479 RST SM 0603 RC21 47R PM5
3501 232270260479 RST SM 0603 RC21 47R PM5
3502 232270260479 RST SM 0603 RC21 47R PM5
3503 212211805669 RST SM 0603 RC0603 10K PM5
3505 232270260101 RST SM 0603 RC21 100R PM5
3506 232270260101 RST SM 0603 RC21 100R PM5
3507 232270260101 RST SM 0603 RC21 100R PM5
3509 232270260221 RST SM 0603 RC21 220R PM5
3510 232270260221 RST SM 0603 RC21 220R PM5
3511 212211805669 RST SM 0603 RC0603 10K PM5
Model: HP L1940(LPL) 12NC: 8639 000 15804
Mechanical Parts
30 313815758111 FRONT BEZEL ASSY
31 313815414111 BEZEL
32 313815414131 CONTROL BUTTON
33 313815414141 LENS-POWER
34 313815161731 HP LOGO 7121 - 8115
41 313815414121 BACK COVER
50 313815758131 STAND-HPL1940
91 313815758121 MAIN SHIELD ASSY
92 313815136221 AC BRACKET
93 313815564901 FRONT COVER
301 313815136141 MAIN FRAME-LPL/CMO
340 313815136151 MAIN SHIELD
Packing Parts
450 313815638761 CARTON
451 313815638461 CUSHION-R
452 313815638471 CUSHION-L
453 313815620801 PE BAG
Accessory
601 313811707601 HP CD-ROM INF.
1157 313818879271 MAINSCORD IEC 10A 1M83 DET BK
1158 313819871252 CORD SUB-D 15/1M8/SUB-D 15 BK
1159 313819873991 CORD USB A/2M/USB B BK
miscellanea
291 313815564931 LABEL-CPU
295 313815564941 LABEL-EEPROM-LPL
298 313815564961 LABEL-EEPROM-USB
615 313811707611 HEX CODE OF F/W(NO MATL REQ)
1160 313815861441 MAIN FRAME+WIRE ASSY - LPL
1201 242203300521 SOC DVI H 24P F 1.91DVI-D
1203 242202518065 SOC SUBD H 15P F BU 900
1302 243803100435 SOC IC V 8P F 2.54 DIL
1410 242254300999 RES XTL SM 14M318 20P SMD-49
1412 242202518682 CON H 30P F 1.00 SM FFC 0.3
1601 242254301447 RES XTL SM 12MHZ 32P SMD-49
1602 823827716661 USB B TYPE RECEPTACLE CONN
1603 823827716671 USBA TYPE DOUBLE PORT CONN
1608 243803100435 SOC IC V 8P F 2.54 DIL
1932 242212803035 SWI TACT SM 1P 1POS SKQGAB
1933 242212803035 SWI TACT SM 1P 1POS SKQGAB
1934 242212803035 SWI TACT SM 1P 1POS SKQGAB
1935 242212803035 SWI TACT SM 1P 1POS SKQGAB
1936 242212803035 SWI TACT SM 1P 1POS SKQGAB
4444 313810610427 CD ROM - SERVICE MANUAL
4444 313810610428 SERVICE MANUAL
8161 313819873981 CBLE-267 7/330/7-267 AWG28
8163 313819873971 FFC 30/180/30 1.0
LCD Panel
1050 932221474682 TFT-LCD LM190E02-A4(H)(LGPH)
PCB Assy
1051 313815859821 SCALER ASSY
1052 823827716171 LIPS(T50P057.00)
1053 313815860161 CONTROL ASSY
PCB Assy
1051 313815859821 SCALER ASSY
2201 223878615649 CER2 0603 X7R 16V 100N PM10
2202 223878615649 CER2 0603 X7R 16V 100N PM10
2203 223878615649 CER2 0603 X7R 16V 100N PM10
2204 223878615649 CER2 0603 X7R 16V 100N PM10
2209 223878615649 CER2 0603 X7R 16V 100N PM10
2214 223878615649 CER2 0603 X7R 16V 100N PM10
2218 223886715339 CER1 0603 NP0 50V 33P PM5
2219 223886715221 CER1 0603 NP0 50V 220P PM5
2220 223878615649 CER2 0603 X7R 16V 100N PM10
2221 223878615649 CER2 0603 X7R 16V 100N PM10
2225 223858615636 CER2 0603 X7R 50V 10N PM10
2227 223858615636 CER2 0603 X7R 50V 10N PM10
2229 223858615636 CER2 0603 X7R 50V 10N PM10
Spare/Recommended Parts List
