HP L1940
Viewing Angle. : Vertical 176 degree, Horizontal 176 degree (CR=10)
Contrast ratio. : 500:1
Luminance. : 250 cd/m
2
(Typ)
b.) Type NR. : M190E3-L01 (CMO)
Number of Pixels. : 1280 (H) x 1024 (V)
Physical Size. : 404.2(H)*330.0(V)*20.0(D) mm
Pixel Pitch. : 0.294 x 0.294 mm
Color pixel arrangement : RGB stripes arrangement
Support Color. : 8 bit (16.7M Colors)
Display Mode. : Transmissive Mode, Normally Black
Backlight. : CCFL edge light system
Active area. (WXH). : 376.32(H) x 301.056(V)mm (19
diagonal)
Viewing Angle. : Vertical 170 degree, Horizontal 170 degree (CR=10)
Contrast ratio. : 800:1
Luminance. : 250 cd/m
2
(Typ)
c.) Type NR. : M190EN03 (AUO) (Option)
Number of Pixels. : 1280 (H) x 1024 (V)
Physical Size. : 396.5(H)*32450(V)*14.33(D) mm
Pixel Pitch. : 0.294 x 0.294 mm
Color pixel arrangement : RGB stripes arrangement
Support Color. : 8 bit (16.7M Colors)
Display Mode. : Transmissive Mode, Normally Black
Backlight. : CCFL edge light system
Active area. (WXH). : 376.32(H) x 301.056(V)mm (19
diagonal)
Viewing Angle. : Vertical 176 degree, Horizontal 176 degree (CR=10)
Contrast ratio. : 700:1
Luminance. : 250 cd/m
2
(Typ)
2.2 Scanning frequencies
H-Frequency. : 30K - 83 K Hz
V-Frequency. : 56 - 76 Hz
2.3 Video dot rate. : < 140 MHz
2.4 Power input. : 90-265 V AC, 50/60 ± 2Hz
2.5 Power consumption. : < 70 W maximum (with USB )
2.6 Dimensions. : 413(W) * 477(H) * 265(D) mm
2.7 Net Weight. : 8.4 kg
2.8 Functions:
(1) D-Sub analog R/G/B separate inputs, H/V sync separated
(2) DVI-D digital Panel Link TMDS input
(3) USB 2.0 HUB with one upstream port and two downstream port
GENERAL PRODUCT SPECIFICATION(Continued)
4
BRAND : HP L1940
19 inch LCD Monitor
TYPE : EJ6B50/02
8639 000 15804
2004-08-31
2004-08-31
590
28
Jacky Lee
