HP L1940

57
HP L1940
3.2.2 DVI Cable
The input signals are applied to the display through DVI-D cable.
Length : 1.8 M +/- 50 mm (fixed)
Connector type : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jack screws
Pin Assignment:
Pin No. Description
1 T.M.D.S. data2-
2 T.M.D.S. data2+
3 T.M.D.S. data2 shield
4 No Connect
5 No Connect
6 DDC clock
7 DDC data
8 No Connect
9 T.M.D.S. data1-
10 T.M.D.S. data1+
11 T.M.D.S. data1 shield
12 No Connect
13 No Connect
14 +5V Power
15 Ground (for +3.3V) - Cable detect
16 Hot plug detect
17 T.M.D.S. data0-
18 T.M.D.S. data0+
19 T.M.D.S. data0 shield
20 No Connect
21 No Connect
22 T.M.D.S clock shield
23 T.M.D.S. clock+
24 T.M.D.S. clock-
3.2.3 OSD Function Control
Philips follow up HP
s requirement to create OSD function and HP approve the OSD
function. If any deviation between SHT590 and customer specification and really product,
production should follow up really product.
OSD (On Screen Display) function
(1) Analog interface OSD:
a. Basic OSD Menu Levels
Analog Mode Menu
Menu LEVEL 1 Menu LEVEL 2
Brightness ADJ Scale
Contrast ADJ Scale
Auto Adjustment
Advanced Menu
Exit
Go to cover page
GENERAL PRODUCT SPECIFICATION(Continued)
7
BRAND : HP L1940
19 inch LCD Monitor
TYPE :EJ6B50/02
8639 000 15804
2004-08-31
2004-08-31
590
28
Jacky Lee
