HP LE2201w User Manual

Icon Main Menu Submenu Description
9300 K Changes to slightly blueish white.
6500 K Changes to slightly reddish white.
Custom Color Selects and adjusts your own color scales:
●
R—sets your own red color levels
●
G—sets your own green color levels
●
B—sets your own blue color levels
sRGB Sets your screen colors to adapt to the color standards
used in the image technology industry.
Quick View Select the viewing mode.
Movie Select the movie mode.
Photo Select the photo mode.
Gaming Select the gaming mode.
Text Select the text mode.
Custom Settings saved when user adjusts the Brightness,
Contrast, or Color in one of the Quick View options.
Language Selects the language in which the OSD menu is
displayed. The factory default is English.
Management Selects the OSD and power management features of
the monitor.
OSD Control Adjusts the position of the OSD menu screen to:
●
Horizontal OSD Position—Changes the viewing
position of the OSD menu to the left or right area
of the screen. The factory default range is 50.
●
Vertical OSD Position—Changes the viewing
position of the OSD menu to the top or bottom
area of the screen. The factory default range is
50.
●
OSD Transparency—Adjust to view the
background information through the OSD
●
OSD Timeout—Sets the time duration in seconds
that the OSD is visible after the last button is
pressed. The factory default is 30 seconds.
●
OSD Rotation (select models)—Rotates the OSD
Menu to support pivot function.
Power Saver Enables the power saving feature. Select:
●
On
●
Off
The factory default is On.
Table 4-2 OSD Menu (continued)
ENWW Adjusting the Monitor Settings 17
Downloaded from ManualMonitor.com Manuals

HP LE2201w Specifications

General

3D	No
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1152 x 870, 1280 x 960, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Plug and Play	Yes
LED indicators	Power
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	161 mm
Package width	587 mm
Package height	489 mm
Package weight	4700 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	35 W
Sync input impedance	75 Ω
Dimensions (W x D x H) (imperial)	20.28 x 2.36 x 13.58 \
Mean time between failures (MTBF)	30000 h
DVI-D ports quantity	0

Weight and Dimensions

Depth (with stand)	207 mm
Height (with stand)	415 mm
Depth (without stand)	60 mm
Width (without stand)	515 mm
Height (without stand)	345 mm
Weight (without stand)	5200 g
