HP M27fwa - Rear Cover Removal

EL-MF877-00 Page 4
Template Revision C
Last revalidation date 19-March-2021
HPI instructions for this template are available at EL-MF877-01
3. Strip two screws from the rear cover，then move rear cover follow the below way
4. Strip four screws from the hinge
Twist out the
screw
Remove the screws with
Screwdriver
Dismantle the rear cover first from
the two marked position
Remove the 8pin FFC from main
board then remove rear cover
Remove the DECO
