Status lights
The status lights provide different information depending on whether the MSM422 is
operating in autonomous mode or controlled mode. For more information on these modes,
see Controlled mode and autonomous mode on page 1-3.
Autonomous mode
In autonomous mode, the status lights provide the following information:
Controlled mode
During startup/discovery in controlled mode, the status lights provide the following
information:
Light State Description
Power Off The MSM422 has no power.
On The MSM422 is powered-on and is fully operational.
Blinking The MSM422 is starting up. If the Power light continues to blink
after several minutes, it indicates that the software failed to load.
Reset or power cycle the MSM422. If this condition persists,
contact HP Support.
Info On The MSM422 is fully operational.
Ethernet Off The port is not connected or there is no activity.
Blinking The port is transmitting or receiving data.
Radio 1, 2 Blinking The radio is transmitting or receiving data.
Status light behavior Description
Power light blinks once every two
seconds.
The MSM422 is starting up.
Power light blinks once per second. The MSM422 is looking for an IP address, or
building the list of VLANs on which to perform
controller discovery. The management tool is
available until discovery occurs.
Power light, Info light, and Ethernet light
blink in sequence from left to right.
The MSM422 has obtained an IP address and is
attempting to discover a controller.
Power light is on. Info and Ethernet
lights blink alternately.
The MSM422 has found a controller and is
attempting to establish a secure management
tunnel with it.
