MSM320/MSM325
Introduction
6-2
Introduction
This chapter shows you how to get started using the MSM320 (E-MSM320) Access Point. This
chapter also applies to the MSM325 (E-MSM325) Access Point with integrated sensor. Only
the term "MSM320" is used throughout the rest of this chapter. It equally applies to the
MSM325.
Package contents
One MSM320 Access Point
Four 2.4-GHz (2-dBi) / 5-GHz (2-dBi) dual-mode omnidirectional antennas
Documentation
Hardware overview
MSM320 key components are identified as follows:
Status lights
The status lights provide different information depending on whether the AP is operating in
autonomous mode or controlled mode. For more information on these modes, see Controlled
mode and autonomous mode on page 1-3.
VIEW
Certified
The MSM320 is a Wi-Fi Alliance authorized Wi-Fi CERTIFIED 802.11a/b/g product. The
Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. The MSM320 is
certified under the SpectraLink Voice Interoperability for Enterprise Wireless (VIEW)
Certification Program when it operates in autonomous mode or in controlled mode in
conjunction with an MSM7xx Controller.
➀
➁
➂➃➄
➅
➆
➀
➅
Front panel
1: Antenna connector
2: Power connector
3: Power light
4: Ethernet port light
5: Radio light
6: Ethernet port
7: Reset button
