HP MSM720 Installation Guide

Network ports
• Access network: Four auto-sensing 10/100/1000Base-T ports. All these ports have the
Auto-MDX feature, which means that you can use either straight-through or crossover twisted-pair
cables to connect any network devices to the controller.
• Internet network: Two dual-personality ports for either 10/100/1000Base-T RJ-45 (Auto-MDX)
uplinks, or optional mini-GBIC (SFP) slots for fiber uplinks.
LEDs
There are three groupings of LEDs on the controller:
• Status LEDs (Table 1 (page 5))
• Port LEDs (Table 2 (page 5))
• Port LED Mode indicator LEDs (near the Mode selector button) (Table 3 (page 6))
Table 1 Status LEDs
MeaningStateStatus LEDs
The controller is powered on.OnPower (green)
No power connection. The controller is NOT receiving power.Off
The controller is beginning its boot sequence. Turns on for three seconds at power
up or reset.
OnFault (orange)
The Locator LED is used to locate a specific MSM720 in an area full of other
controllers and MSM720s. The LED can be set to be on solid or blink for a
OnLocator (blue)
Blinking
specified number of minutes (1-1440). The default is 30 minutes. Use the command
“chassislocate”.
Off
The normal operational state; the controller is not undergoing self test.OffTest (green/orange)
Lights during power up self test and stays on until the controller is ready to receive
traffic.
On (green)
Port LEDs
The port LEDs provide information about the individual ports.
Table 2 Port LEDs
MeaningStateStatus LEDs
Port LEDs
The port is enabled and receiving a link indication from the connected device.OnLink (green)
One of these condition exists:Off
• No active network cable is connected to the port
• The port is not receiving link beat or sufficient light
• The port has been disabled through the controller console, the Web browser
interface, HP Manager, or other network management tool
Indicates Activity, Duplex, or Speed according to Mode selected. See “LED mode select button
and indicator LEDs” (page 6) for details.
Mode (green)
Mini-GBIC LEDs
Identifying front-panel features 5
