Installing the router
Mounting the router on a workbench
IMPORTANT:
• Allow 10 cm (3.94 in) of clearance around the chassis for heat dissipation.
• Do not place heavy objects on the router.
To mount the router on a workbench:
1. Make sure the workbench is clean, stable, and reliably grounded.
2. Place the router upside down on the workbench and attach the rubber feet to the four round holes
in the chassis bottom.
Figure 3 Attaching the rubber feet
3. Place the router on the workbench with the upside up.
Figure 4 Mounting the router on a workbench
Installing the router in a rack
ARNING!
The mountin
brackets can only support the wei
ht of the router. To avoid dama
e to the router, do not
place any objects on the router.
To install the router in a rack:
9
