HP MSR1003-8S Installation Guide

Appendix B LEDs
Panel LEDs
Figure 37 MSR1002-4 LEDs
3
4
(1) Asynchronous/synchronous
serial interface LED (SERIAL0)
(2) SFP port LED (SFP5) (3) Power supply LED (PWR)
(4) System status LED (SYS) (5) 10/100 Mbps link LED for the
Gi
g
abit Ethernet port
(6) 1000 Mbps link LED for the
Gi
g
abit Ethernet port
Figure 38 MSR1003-8 LEDs
(1) System LED (SYS) (2) Power supply LED (PWR) (3) Gigabit Ethernet port LEDs (GE0 to GE9)
Figure 39 MSR1003-8S LEDs
(1) System LED (SYS) (2) Power supply LED (PWR) (3) Gigabit Ethernet port LEDs (GE0 to GE9)
5 6
2
5 6
1
34
