MSR1003-8
Figure 33 Front view
(1) Power receptacle (2) Gi
abit Ethernet port (GE1)
(3)
Gi
abit Ethernet ports (GE2 to GE8)
(4) Console port/AUX port
(CON/AUX)
(5) Reset button (RESET) (6) USB port
(7) Gigabit Ethernet port (GE0)
Figure 34 Rear view
(1) SIC slot 3 (2)
SIC slot
2
(3) SIC slot 1 (4) Groundin
terminal
MSR1003-8S
Figure 35 Front view
(1) Power receptacle (2) Gigabit Ethernet port (GE1)
(3) Gigabit Ethernet ports (GE2 to GE8)
(4) Console port/AUX port
(CON/AUX)
(5) Reset button (RESET) (6) USB port
(7) Gi
abit Ethernet port (GE0)
