HP MSR1003-8S Installation Guide

Appendix A Chassis views and technical
specifications
Chassis views
The following figures are for illustration only.
MSR1002-4
Figure 31 Front view
(1) Power receptacle (2) Gi
g
abit Ethernet port (GE0) (3) Gi
g
abit Ethernet ports (GE1 to GE4)
(4) SFP port (SFP5) (5) Asynchronous/synchronous
serial interface (SERIAL0)
(6) Console port/AUX port (CON/AUX)
(7) Reset button (RESET) (8) USB port
Figure 32 Rear view
(1) SIC slot 2 (2) SIC slot 1 (3) Groundin
g
terminal
31

HP MSR1003-8S Specifications

General

Brand	HP
Model	MSR1003-8S
Category	Network Router
Language	English
