Installing the Switch
The 1820 Switches are easy to install. They come with an accessory kit that includes the brackets for
mounting the switches in a standard 19-inch telco rack, in an equipment cabinet, and with rubber feet that can
be attached so the switches can be securely located on a horizontal surface. The brackets are designed to
allow mounting of the switches in a variety of locations and orientations. This chapter shows how to install the
switches.
Included Parts
The following components ship with an 1820 Switch:
Documentation kit
• Quick Setup Guide
• Safety and Regulatory information
• Software License, Warranty, and Support information
• Accessory kits:
1820 8G and 1820 8G PoE+ Switch
Kit number 5066-2232
• two rack mounting brackets
• eight 8-mm M4 screws to attach the mounting
brackets to the switch
• four 5/8-inch number 12-24 screws to attach the
switch to a rack
• four rubber feet
Kit number 5066-0621
• three 3/4” (20-mm M4) screws for wall and under-
table mounting
• three wall anchors
• cable tie for power cord
1820 24G, 1820 24G PoE+,and 1820 48G Switch 1820 48G PoE+ Switch
Kit number 5069-6535
• two wall/table mounting brackets
• eight 8-mm M4 screws to attach the mounting
brackets to the switch
• four 5/8-inch number 12-24 screws to attach the
switch to a rack
• four rubber feet
Kit number 5069-5705
• two rack mounting brackets
• eight 8-mm M4 screws to attach the mounting
brackets to the switch
• four 5/8-inch number 12-24 screws to attach the
switch to a rack
• four rubber feet
Kit number 5092-0769
• two wall/table mounting brackets
• 1820 24- and 48-port switch AC power cords, one of the following:
Country/Region 1820 24G, 1820 48G,
and 1820 24G PoE+
1820 48G PoE+
1
Argentina 8120-6869 8120-8375
Australia/New Zealand 8121-0834 8121-0857
Table Continued
12 Installing the Switch
