Mounting the display head
You can remove the display head from the stand to install the display head on a wall, a swing arm, or other
mounting xture.
NOTE: This apparatus is intended to be supported by a UL- or CSA-Listed wall mount bracket.
CAUTION: This monitor supports the VESA industry-standard 100 mm mounting holes. To attach a third-
party mounting solution to the display head, four 4 mm, 0.7 pitch, and 10 mm long screws are required.
Longer screws must not be used because they may damage the display head. It is important to verify that the
manufacturer’s mounting solution is compliant with the VESA standard and is rated to support the weight of
the display head. For best performance, it is important to use the power and video cables provided with the
monitor.
Removing the monitor stand
CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned o and all cables are
disconnected.
1. Disconnect and remove all cables from the monitor.
2. Lay the monitor facedown on a at surface covered by a clean, dry cloth.
3. Press down on the release latch (1) and slide the stand o the connector on the display head (2).
4. Loosen the thumbscrew (3) and remove the base from the neck (4).
6 Chapter 1 Getting Started
