Attaching the VESA mounting bracket
A VESA mounting bracket is included with the monitor for use when attaching the display head to a wall,
swing arm, or other mounting xture.
1. Remove the monitor stand. Refer to Removing the monitor stand on page 6.
2. Press the connector on the VESA bracket onto the connector on the back of the display head until the
bracket clicks into place.
3. To attach the display head to a swing arm or other mounting device, insert four mounting screws
through the holes on the mounting device and into the screw holes on the VESA bracket that was
installed on the rear of the display head.
IMPORTANT: Follow the mounting device manufacturer’s instructions when mounting the monitor to a
wall or swing arm.
IMPORTANT: For optimal monitor performance and screen clarity, do not rotate the monitor 90
degrees to portrait orientation.
Setting up the monitor 7
