HP OMEN Maintenance And Service Guide

6 Removal and replacement procedures for
authorized service provider parts
CAUTION: Components described in this chapter should be accessed only by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
Component replacement procedures
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer. See Locating system information on page 15 for
details.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
There are as many as eighty-six screws that must be removed, replaced, and/or loosened when servicing the
parts described in this chapter. Make special note of each screw size and location during removal
and replacement.
Component replacement procedures 39

HP OMEN Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
Tilt angle range	-5 - 23 °
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
HP segment	Home
Cables included	AC, HDMI, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	227.5 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Width (without stand)	569 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
