HP OMEN Maintenance And Service Guide

Display panel
NOTE: The display panel spare part kit does not include the display cable or display panel brackets.
Description Spare part number
15.6 in, WLED, FHD, UWVA, eDP display panel for use with AMD R17M GPU 752920-019
15.6 in, WLED, FHD, UWVA, eDP+NVSR display panel for use with N17E GPU 923006-001
15.6 in, WLED, FHD, UWVA, EDP+PSR display panel for use with N17P GPU 930619-001
15.6 in, WLED, UHD, UWVA, eDP+NVSR display panel for use with N17E GPU 920041-002
15.6 in, WLED, UHD, UWVA, EDP+PSR display panel for use with N17P GPU 929115-002
Display and webcam cable for use only on models equipped with an ultra high denition (UHD) panel and
infrared webcam
929454-001
Display and webcam cable for use only on models equipped with an ultra high denition (UHD) panel and
standard webcam
929453-001
Display and webcam cable for use only on models equipped with an full high denition (FHD) panel and
infrared webcam
929452-001
Display and webcam cable for use only on models equipped with an full high denition (FHD) panel and
standard webcam
929451-001
Display panel bracket, left 929461-001
Display panel bracket, right 929460-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the display panel, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 33), and then remove the following components:
a. Hinge covers (see Hinge covers on page 48).
b. System support brackets (see System support brackets on page 49).
c. Heat sink (see Heat sink on page 56).
d. System board (see System board on page 61).
e. Display assembly (see Display assembly on page 65).
f. Display bezel (see Display bezel on page 70).
Remove the display panel:
1. Remove the six Phillips PM1.9×3.5 screws (1) that secure the brackets to the display assembly.
76 Chapter 6 Removal and replacement procedures for authorized service provider parts
