HP OMEN Maintenance And Service Guide

TouchPad
NOTE: The TouchPad spare part kit includes the TouchPad connector cable, but does not include the
TouchPad bracket.
Description Spare part number
TouchPad board (with connector cable) 929472-001
TouchPad bracket 929462-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the TouchPad, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 33), and then remove the following components:
▲
Speakers (see Speakers on page 42).
Remove the TouchPad:
1. Disconnect the TouchPad connector cable from the system board (1).
2. Disconnect the TouchPad from the keyboard/top cover (2).
3. Remove the 4 Phillips PM2.0×3.4 screws (3).
4. Remove the TouchPad bracket.
46 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP OMEN Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
Tilt angle range	-5 - 23 °
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
HP segment	Home
Cables included	AC, HDMI, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	227.5 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Width (without stand)	569 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
