HP OMEN Maintenance And Service Guide

Power button board
NOTE: The power button board does not include the power button board connector cable.
Description Spare part number
Power button board 929468-001
Power button board connector cable 929448-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the power button board, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 33), and then remove the following components:
a. Hinge covers (see Hinge covers on page 48).
b. System support brackets (see System support brackets on page 49).
c. Fans (see Fans on page 52).
d. Heat sink (see Heat sink on page 56).
Remove the power button board:
1. Disconnect the power button board cable from the system board (1).
2. Remove the two Phillips PM2.0×3.5 screws (2) that secure the power button board to the computer.
Component replacement procedures 59

HP OMEN Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
Tilt angle range	-5 - 23 °
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
HP segment	Home
Cables included	AC, HDMI, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	227.5 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Width (without stand)	569 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
