Table 3-2 Display components and their descriptions (continued)
Item Component Spare part number
FHD, non-touch, 250 nits L62773-001
FHD, non-touch, privacy L62774-001
FHD, touch-on panel (TOP), privacy, 400 nits L62771-001
(3) Hinge cover L14376-001 (Hinge Kit)
(4) Ambient light sensor board (includes double-sided tape) L62745-001
(5) Camera module
HD camera L62742-001
IR camera L64702-001
Microphone module (includes double-sided tape; not shown) L62744-001
(6) Camera cable (HD and IR models) L64668-001 (Cable Kit)
(7) Hinges (left and right) L14376-001 (Hinge Kit)
(8) WLAN antenna (available with display enclosure)
(9) WWAN antenna (available with display enclosure)
(10) Display cable L64668-001 (Cable Kit)
(11) Display enclosure (includes tape, gasket, and foam for display) L62729-001
Plastics Kit
24 Chapter 3 Illustrated parts catalog
