2-2 Removal and Replacement Service Manual
Table 2-2. Required Equipment
•
#0 and #1 Phillips screwdrivers, preferably magnetized.
•
Small flat-blade screwdriver.
•
5 mm nut driver
Table 2-3. Recommended Screw Torque Values
Screw Thread Size Torque (cm-kgf) Torque (in-lbf)
M2 2,0 – 2,5 1.7 – 2.2
M2.5 (hinges) 3,5 – 4,0 3.0 – 3.4
M2.5 (other) 2,5 – 3,0 2.2 – 2.6
M3 2,5 – 3,0 2.2 – 2.6
Standoff, hex 2,5 – 3,0 2.2 – 2.6
