HP PAVILION 1100 - Figure 2-15. Removing the I;R PCA

2-26 Removal and Replacement Service Manual
Reassembly Note
Caution
Use care when handling the I/R PCA cable. Damaging the cable can degrade notebook
performance.
•
Make sure you route the I/R PCA cable between the left screw hole and the bottom case.
Figure 2-15. Removing the I/R PCA
Screw,
M2.5×4mm (2)
