Service Manual Removal and Replacement 2-7
Removing the Hard Disk Drive
(User-Replaceable)
Required Equipment
•
#1 Phillips screwdriver.
Removal Procedure
Important
If you are installing a new hard disk drive, load the factory software and operating system on the
drive as described in “Recovering the Factory Software,” as shown on the next page.
1.
Unplug the AC adapter, if present, and then remove the battery.
2.
On the bottom of the notebook, remove the hard drive rubber screw plugs and retaining screws.
3.
Carefully pull the hard drive out of the notebook.
Figure 2-5. Removing the Hard Disk Drive
Screw, M2.5×6mm (2)
