TIP: When installing a panel into the display, use the alignment marks (1), and then press the
adhesive tape onto each side of the display enclosure (2).
b. Swing the top edge of the display panel (1) forward until the panel rests upside down next to the
display.
c. Release the adhesive support strip (2) that secures the display panel cable connector to the
display panel.
Component replacement procedures 49
