Display assembly subcomponents
Item Component Spare part number
(1) Bezel
For non-touch screens 856725-001
For non-touch 3D screens 856726-001
(2) Camera
NM USB 3.0 1080p Intel 3D (only for 15-bc300~399, 15-bc400~499 models) 781624-005
DM USB 2.0 Mjpeg 720p VDH2 PA (only for 15-bc300~399, 15-bc400~499 models) 833962-011
DM USB 2.0 Mjpeg 720p VDH SF (only for 15-bc300~399, 15-bc400~499 models) 846006-003
DM USB 2.0, HD, Mjpeg, VDHC, TL (used in all models) L02666-001
Microphone board 857471-001
26 Chapter 3 Illustrated parts catalog
