CAUTION: To prevent damage to the memory module, hold the memory module by the edges only. Do not
touch the components on the memory module.
1. Align the notched edge of the module with the tab in the slot (1), and then press the module into the slot
at an angle until it is seated (2).
2. Press down on the module until the side retention clips snap into place (3).
Component replacement procedures 43
