HP Pavilion M50 User Manual

5 Technical Information
HP Pavilion Multimedia Displays
40
M50 Display Information
Picture tube 15 in (38.1 cm), 90°
deflection, non-
glare, black matrix,
light transmission
57% phosphor P22
medium short, 0.28
mm dot pitch
Maximum
viewable area
280 mm (H) x 210 mm
(V)
11 in (H) x 8.25 in
(V)
Line
(horizontal)
frequency
30–54 kHz
Raster
(vertical)
frequency
50–100 Hz
Power source 100–240 VAC, 50/60
Hz
Maximum power
consumption
90 W
Dot rate 65 MHz
Pedestal Tilt: -5° forward,
12° backward
Swivel: 90° left or
right
Dimensions
(W x H x D)
372 x 401 x 395 mm
14.9 x 16.0 x 15.8
in

HP Pavilion M50 Specifications

General

Brand	HP
Model	Pavilion M50
Category	Monitor
Language	English
