5 Removal and replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
CAUTION: This computer does not have user-replaceable parts. Only HP authorized service providers should
perform the removal and replacement procedures described here. Accessing the internal part could damage
the computer or void the warranty.
Component replacement procedures
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer. See {Xref Error! Target does not exist.} for details.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
There are as many as 58 screws that must be removed, replaced, and/or loosened when servicing Authorized
Service Provider only parts. Make special note of each screw size and location during removal
and replacement.
Keyboard/top cover
For use in country/region Spare part number For use in country/region Spare part number
In ash silver nish with backlight for use only on computer models equipped with a graphics subsystem with discrete memory
(includes backlight cable and keyboard cable):
For use in Canada 924525-DB1 For use in the United States 924525-001
In ash silver nish with backlight for use only on computer models equipped with a graphics subsystem with UMA memory
(includes backlight cable and keyboard cable):
For use in Canada 924524-DB1 For use in the United States 924525-001
In ash silver nish for use only on computer models equipped with a graphics subsystem with discrete memory
(includes keyboard cable):
For use in Belgium 924523-A41 For use in Latin America 924523-161
For use in Bulgaria 924523-261 For use in the Netherlands 924523-B31
For use in Canada 924523-DB1 For use in Portugal 924523-131
For use in the Czech Republic
and Slovakia
924523-FL1 For use in Romania 924523-271
For use in Denmark, Finland,
and Norway
924523-DH1 For use in Russia 924523-251
For use in France 924523-051 For use in Saudi Arabia 924523-171
For use in Germany 924523-041 For use in Slovenia 924523-BA1
24 Chapter 5 Removal and replacement procedures
