5. Remove the TouchPad (2).
Reverse this procedure to install the TouchPad.
Battery
Description Spare part number
3-cell, 48-WHr, 4.2-AHr, Li-ion battery 916812-855
Before removing the battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 24).
Remove the battery:
1. Release the ZIF connector (1) to which audio jack board cable is connected, and then disconnect
the audio jack board cable (2) from the system board.
2. Detach the audio jack board cable (2) from the battery. (The audio jack board cable is attached to
the battery with double-sided adhesive.)
3. Remove the seven Phillips PM2.0×4.6 screws (3) that secure the battery to the computer.
30 Chapter 5 Removal and replacement procedures
