12. If you need to remove the camera module:
▲ Use a tool (1) to lift up evenly across the module and peel the module up from the display back
cover (2), and then disconnect the cable from the reverse ZIF connector on the module (3). The
camera module is available as spare part number M48775-001.
NOTE: For installation, note that the cable routes under the camera module before it connects to
the module.
13. If you need to remove the camera cable, remove the tape (1), peel the cable from the locations it is
adhered to the inside of the display back cover (2), and then remove the cable (3).
The camera cable is available as spare part number M45390-001.
52
Chapter 5Removal and replacement procedures for authorized service provider parts
